Automann Phoenix AB1DK10B-5409 Air Spring Rolling Lobe

Description

Automann Bellows# : 1DK10B
Bottom Part # : BS12900
Bottom Plate C to C Dia. (D) : N/A
Bottom Plate Dia. (C) : 7.24
Bottom Plate Hole/Stud Qty : 1
Bottom Plate Type : Steel
Bracket : N/A
Bumper : No
Contitech Bellows# : 6 6.5-13
Design Height (In) : 10.00
Max. Height : 16.50
Min. Height : 4.70
Natural Freq. (CPM) : 80
Top Plate C to C Dia. (B) : 3.38
Top Plate Dia. (A) : 6.31
Top Plate Hole/Stud Qty : 2
Type : Rolling Lobe

• Part number: AB1DK10B-5409
• OE MFG: Contitech
• OEM Reference: 68136
• Cross Reference: CHEVROLET/GM : 716111; CONTITECH : 665-13S039, 665-13S056, 68121, 68136; FIRESTONE : 5406, 5409, 5435, W013585406, W013585409, W01-358-5409, W01-358-5435; FLEXIBLE : 6-336-11; GMC : 662743, 8865456; GOODYEAR : 1R9003, 1R9-003, 1R9038; GRANNING : 15765, 1971; NEW FLYER : 5920815, 5973877, 5973923, 5993113; SLOAN : 490000, 5622009; TECTRAN : 201009 | AUTOMANN : 562.2009, AB1DK10B-5406
