Automann Phoenix AB1DK23K-9643 Air Spring Rolling Lobe

Description

Automann Bellows# : 1DK23K
Bottom Part # : BS08660
Bottom Plate C to C Dia. (D) : N/A
Bottom Plate Dia. (C) : 10.00
Bottom Plate Hole/Stud Qty : 1
Bottom Plate Type : Plastic
Bracket : AB9372P or AB9373P
Bumper : Yes
Contitech Bellows# : 9 10-16
Design Height (In) : 11.00
Load (Lbs)
100 PSI : 7500
Load (Lbs)
80 PSI : 5900
Max. Dia. : 12.60
Max. Height : 20.70
Min. Height : 6.60
Natural Freq. (CPM) : 64
Top Plate C to C Dia. (B) : 6.20
Top Plate Dia. (A) : 9.00
Top Plate Hole/Stud Qty : 2
Triangle Bellows# : 6363
Type : Rolling Lobe

• Part number: AB1DK23K-9643
• OE MFG: Contitech
• OEM Reference: 910-16P549
• Cross Reference: CONTITECH : 64322, 69658, 910-16P549; FIRESTONE : 9643, W013589643, W01-358-9643, W014559643, W01-455-9643; HENDRICKSON : 58995-2; HENDRICKSON TRUCK : 58995002, 58995-002, 58995002L, 58995-002L, 589952 |
